Gigabyte Motherboard H810M H s1851 H810 2xDDR5 M.2 HDMI D-Sub mATX (H810M_H)

Name: Gigabyte Motherboard H810M H s1851 H810 2xDDR5 M.2 HDMI D-Sub mATX (H810M_H)
Brand: Gigabyte
SKU: H810M_H
Price: 5096.00 UAH
Availability: InStock

Brand: Gigabyte Product Code: H810M_H

All about product

Description

Specification

Reviews 0

Questions0

new

ХІТ

Gigabyte Motherboard H810M H s1851 H810 2xDDR5 M.2 HDMI D-Sub mATX (H810M_H)

In Stock

5096.00 ₴

Found cheaper?

Buy this product in 1 click:

Guarantee:36 мес.

Features:S/PDIF out header, CPU fan header, system fan headers, clear CMOS jumper, serial port header, iTE I/O Controller Chip, Front panel audio connector, Support for Windows 10 64-bit, Smart Backup function, Q-Flash utility, Front Panel Header, TPM Header, Voltage detection, Temperature detection, Fan speed detection, Fan fail warning, Fan speed control, Water cooling flow rate detection, Support for Windows 11 64-bit

Towards:gaming (overclocking)

Form Factor:micro-ATX

Connection type:LGA 1851

Delivery

Nova Poshta by courier around the city

according to the carrier's tariffs

Nova Poshta at the branch and post office

according to the carrier's tariffs

Payment

ApplePay

payment on account

in cash

Gigabyte Motherboard H810M H s1851 H810 2xDDR5 M.2 HDMI D-Sub mATX (H810M_H)

5096.00 ₴

Description

The GIGABYTE H810M H is a compact mATX motherboard built on the latest Intel H810 chipset, supporting Intel Core Ultra processors (LGA1851) and up to 128 GB of DDR5 memory. It features HDMI 2.1 and D-Sub outputs, M.2 PCIe 4.0 SSD support, and 4 SATA ports with RAID capability.

Tags: Gigabyte, Motherboard, H810M, H, s1851, H810, 2xDDR5, M2, HDMI, DSub, mATX, H810MH

Specifications

Additional information

Features

S/PDIF out header, CPU fan header, system fan headers, clear CMOS jumper, serial port header, iTE I/O Controller Chip, Front panel audio connector, Support for Windows 10 64-bit, Smart Backup function, Q-Flash utility, Front Panel Header, TPM Header, Voltage detection, Temperature detection, Fan speed detection, Fan fail warning, Fan speed control, Water cooling flow rate detection, Support for Windows 11 64-bit

Audio settings

Аudiochip

Realtek®

Sound

7.1, 5.1, 2, 4

Chipset

Northbridge (chipset)

Intel H810

UEFI BIOS

Есть

BIOS

UEFI

Connecting drives

Connection interface

SATA 3, M.2

SATA3 (6 Gb / s)

4 ports

Support software RAID

Есть (0/1/5/10 для SATA)

Connection connectors

USB 2.0, pcs

7 (Chipset: 1 порт на задній панелі, 2 порти доступні через внутрішній USB-роз'єм; Chipset+USB 2.0 Hub: 4 порти USB 2.0/1.1 на задній панелі)

USB 3.2 Gen 1

4 (1xUSB Type-C® з підтримкою USB 3.2 Gen 1, доступний через внутрішній USB-роз'єм; 1 порт на задній панелі, 2 порти доступні через внутрішній USB-роз'єм)

M.2 connector

PS/2, pcs

1 (клавіатура/миша)

CPU

Connection type

LGA 1851

For processors

Intel

Guarantee

36 мес.

Main

Towards

gaming (overclocking)

Form Factor

micro-ATX

Network interfaces

LAN (RJ-45)

10/100/1000 Mbps

Number of LAN-ports

LAN-Controller Model

Realtek GbE

Physical

Dimensions (HxW)

244 x 215

Main power connector

24+8 -pin

RAM

Connector type

DDR5

Maximum operating frequency, MHz

6400

The maximum amount of memory, GB

128

DDR5

2 slots

Video settings

Graphical interface

PCI-E x16 4.0, PCI-E x1 3.0

HDMI Output

Есть

D-Sub (VGA)

Есть
